WR-PHONELIC

Description

Application

Materials

TECHNICAL DATA

Temperature	-60°C / +150°C (+200°C)
Pressure	0 MPa
Speed	15 m/s
Medias

MATERIALS

DIMENSION

Part Number	Nominal Nymber	d	D	h	t	H
GW0241 PO	18	14	18	8	2	8
GW0242P0	19.2	15.2	19.2	8	2	8
GW0243P0	20	16	20	8	2	8
GW0244P0	22	18	22	8	2	8
GW0245P0	24	20	24	8	2	8
GW0246P0	25	21	25	8	2	8
GW0247P0	26	22	26	8	2	8
GW0248P0	28	24	28	8	2	8
GW0249P0	30	26	30	8	2	8
GW0250PO	31	27	31	8	2	8
GW0251 PO	31.5	27.5	31.5	8	2	8
GW0252P0	33	29	33	10	2	10
GW0253P0	35	31	35	10	2	10
GW0254P0	35.4	31.4	35.4	10	2	10
GW0255P0	35.5	31.5	35.5	10	2	10
GW0256PO	38	34	38	10	2	10
GW0257P0	40	36	40	10	2	10
GW0258P0	41	37	41	15	2	15
GW0259P0	43	388	43	15	2.5	15
GW0260P0	44.5	39.5	44.5	15	2.5	15
GW0261 PO	45	40	45	15	2.5	15
GW0006P1	50	45	50	15	2.5	15
GW0263P0	51.5	46.5	51.5	15	2.5	15
GW0264P0	55	50	55	15	2.5	15
GW0010P1	56	51	56	15	2.5	15
GW0012P1	60	55	60	15	2.5	15
GW0267P0	61	56	61	15	2.5	15
GW0268P0	63	58	63	15	2.5	15
GW0269P0	65	60	65	20	2.5	20
GW0270P0	66	61	66	20	2.5	20
GW0271P0	69	64	69	20	2.5	20
GW0019P1	70	65	70	20	2.5	20
GW0192P1	71	66	71	20	2.5	20
GW0021P1	75	70	75	20	2.5	20
GW0746P0	76	71	76	20	2.5	20
GW0027P1	80	75	80	20	2.5	20
GW0030P1	85	79	85	25	3	25
GW0036P1	90	84	90	25	3	25
GW0167P1	95	89	95	25	3	25
GW0041 P3	100	94	100	25	3	25
GW0278PO	105	99	105	25	3	25
GW0051P1	110	104	110	25	3	25
GW0280PO	112	106	112	30	3	30
GW0055P2	115	109	115	30	3	30
GW0059P1	120	114	120	30	3	30
GW0283PO	125	119	125	30	3	30
GW0065P1	130	123	130	30	3.5	30
GW0285PO	132	125	132	35	3.5	35
GW0075P1	140	133	140	35	3.5	35
GW0086P1	150	143	150	35	3.5	35
GW0287PO	157	150	157	40	3.5	40
GW0093P2	160	153	160	40	3.5	40
GW0289PO	165	157	165	45	4	45
GW0290PO	170	162	170	45	4	45
GW0104P1	180	172	180	45	4	45
GW0292PO	185	177	175	45	4	45
GW0293PO	190	182	190	45	4	45
GW0109P1	200	192	200	45	4	45
GW0181P1	205	197	205	50	4	50
GW0296PO	210	212	220	50	4	50
GW0297PO	220	212	220	50	4	50
GW0298PO	224	216	224	50	4	50
GW0115P1	225	217	225	50	4	50
GW0300PO	230	222	230	55	4	55
GW0301 PO	240	232	240	55	4	55
GW0122P1	250	242	250	55	4	55
GW0303PO	260	252	260	60	4	60
GW0304PO	270	262	270	60	4	60
GW0305PO	275	267	275	60	4	60
GW0307PO	290	282	290	70	4	70
GW0308PO	297	289	297	70	4	70
GW0309PO	300	292	300	70	4	70
GW0310PO	312	304	312	70	4	70
GW0311PO	332	324	332	70	4	70
GW0249P0	30W	26	30	8	2	8
GW0251P0	31.5W	27.5	31.5	8	2	8
GW0314P0	32W	28	32	8	2	8
GW0315P0	35W	31	35	8	2	8
GW0316P0	35.5W	31.5	35.5	8	2	8
GW0317P0	40W	36	40	8	2	8
GW0318P0	45W	40	45	8	2.5	8
GW0279P0	50W	45	50	8	2.5	8
GW0319P0	55W	50	55	8	2.5	8
GW0320P0	56W	51	56	8	2.5	8
GW0321 PO	60W	55	60	8	2.5	8
GW0322P0	63W	58	63	8	2.5	8
GW0323P0	65W	60	65	10	2.5	10
GW0324P0	69W	64	69	10	2.5	10
GW0018P1	70W	65	70	10	2.5	10
GW0326P0	71W	66	71	10	2.5	10
GW0327P0	75W	70	75	10	2.5	10
GW0025P1	80W	75	80	10	2.5	10
GW0329P0	85	79	85	15	3	15
GW0330P0	90	84	90	15	3	15
GW0331P0	95	89	95	15	3	15
GW0332P0	100	94	100	15	3	15
GW0333P0	108	102	108	15	3	15
GW0334P0	110	104	110	15	3	15
GW0335P0	112	106	112	15	3	15
GW0336P0	120	114	120	15	3	15
GW0337P0	125	119	125	15	3	15
GW0338P0	130	123	130	15	3.5	15
GW0339P0	140	133	140	20	3.5	20
GW0340P0	150	143	150	20	3.5	20
GW0341P0	160	153	160	20	3.5	20
GW0342P0	170	162	170	25	4	25
GW0343P0	180	172	180	25	4	25
GW0344P0	190	182	190	25	4	25
GW0345P0	200	192	200	25	4	25
GW0346P0	204	196	204	25	4	25
GW0347P0	210	202	210	25	4	25
GW0348P0	224	216	224	25	4	25
GW0349P0	225	217	225	25	4	25
GW0350P0	230	222	230	30	4	30
GW0351 PO	240	232	240	30	4	30
GW0352P0	250	242	250	30	4	30
