TECHNICAL DATA
TECHNICAL DATA
Temperature | None -35°C/+90°C |
Pressure | None 50 MPa |
Speed | None 0.5 m/s |
Medias | None Mineral hydraulic oils |
MATERIALS
MATERIALS
NONE
Polyurethane is a material that has the elastic properties of rubber. The proportion in its composition (diisocyanate, polyol, chain extender) is determined by its properties. This material is characterised by a strong mechanical resistance, good wear resistance, high elastic modulus, good flexibility and a very good ozone and oxidation resistance.
Chemical resistance | Pure aliphatic hydrocarbons (propane, butane) Mineral oils and greases Silicone oils and greases Water up to +50°C |
---|---|
Compatibility issue | Ketones, esters, ethers, alcohols and glycols Hot water, steam, alkalis, amines and acids |
Temperature range | -30°C/+90°C -30°C / +110°C with our PUHT (short term peak at 150°C) |
DIMENSION
DIMENSION
Item | Internal Diameter (d) | Outside Diameter (D1 H8) | Height (H) | Height (h) |
---|---|---|---|---|
SVY-12 | 12 | 24 | 2 | 7 |
SVY-19 | 19 | 35 | 2 | 7 |
SVY-22 | 22 | 34 | 2 | 7 |
SVY-22 | 22 | 40 | 2 | 7 |
SVY-26 | 26 | 44 | 2 | 7 |
SVY-27 | 27.8 | 40.8 | 5 | 1 |
